- Width: 786
- Depth: 870
- Height: 1052
- Weight: 136.400000
- Packaging Width: 870
- Packaging Depth: 970
- Packaging Height: 1200
- Packaging Weight: 173.4
- Power: 17/20.1 KW
- Heating Power: 2x9 KW
- Motor Power: 2x330 W
- Volts: 380/415 3N~
- Combi Oven Temperature: 30-260 ℃
- Combi Oven Max Temperature: 260 ℃
SPECIFICATIONS:
- Holds up to 10 full size sheet pans s on exclusive grab & go racks
- Touchscreen controls with picture-based selections for pre-programmed recipes
- Automatically selects optimal humidity based on temperature and time for no-fuss combi mode
- Self-cleaning and descaling for convenient, quick maintenance
- Increased labor savings due to easy-to-use and consistent programmed recipes
TRIPLE TEMPERED GLASS
Door with low emission triple tempered glass. Easy to clean.
STEAM CONTROL
Humidity control with automatic steam retention/expulsion system.
10" TOUCH DISPLAY
Capacitive display with simple and intuitive graphics.
WORKING MODES
Cooking programmes and additional functions:
- timed manual cooking with core probe and delta T;
- automated cooking with customisable recipe book;
- bakery products cooking;
- steam cooking;
- grill and roast cooking;
- low temperature cooking;
STAINLESS STEEL HINGE
The hinge is made entirely of stainless steel. Excellent materials, long life.
WASHING SYSTEM
Automatic programmable washing system with integrated and separate trays for detergent and descaling agent. Retractable shower-head included.
SMART COOKING
The Smart Cooking function continuously and automatically monitors each cooking process, obtaining the highest level of uniformity and performance.
PARTIAL SPLIT RESISTORS
Maximized energy saving and absolute temperature uniformity in the cooking chamber.
8-SPEED MOTOR
Each motor is equipped with an integrated encoder with speed differential monitoring and capacitive control of anomalies.
8-speed fans with integrated reverse function.
CUSTOMISABLE TIMERS
Possibility of synchronising cooking start / end times for all trays.
MEASURING CORE PROBE
Core probe, with 4 measuring points to support optimal cooking and monitoring.
INTELLIGENT TOUCH SCREEN
Highly responsive, heat-insulated 10" HD screen.
RECIPE BOOK
User Friendly Recipe Book. Possibility of selecting preset recipes and/or inserting your own recipes.
WI-FI CONNECTION
Wi-Fi connection with remote monitoring and diagnostics via iOS/Android app.
AUTOMATIC WASHING
Equipped with 5 automated washing modes, this sytem ensures optimal hygiene and effective scale removal
REMOTE CONTROL APP
The App provides comprehensive recipe book management and real-time cooking timer. Monitoring on both iOS and Android devices, it also offers instant alerts for any detected cooking anomalies.
SEC 2.0
The high degree of insulation of the cooking chamber and chimney combined with the adoption and engineering of state-of-the-art fans for heat extraction and top-quality components allow all oven models to be protected from damage caused by high temperatures, ensuring levels of efficiency and durability never achieved before*
NOTE:
-
No electrical cable supplied with ovens. See page 10 of brochure for pricing. We can cut to size at a per metre rate.
-
All ovens, except for those being installed in WA or SA (or areas of poor water quality), will be supplied with an install kit package - ATOSA-AX12TXSIM -
complete with triple action filter and bracket, dual check valve, water pipe and connectors, Also included is one sample 2L bottle
of Atosa-Wash and one sample 2L bottle of Atosa-Rinse. - All WA and SA ovens (or areas of poor water quality), will be supplied only with a ATOSA-RODCV-15mm dual check valve and one sample 2L bottle of
Atosa-Wash and one sample 2L bottle of Atosa-Rinse, These ovens will require a reverse osmosis system,
Please see below in the "Filtration and Connectors" section for more information on reverse osmosis system options, - Extended 2nd year labour only applies when installed by a SIMCO-authorized installer.
Warranty: 2 Years Parts & 1 Year Labour
