Convotherm 22-Tray Gas Combi-Steamer Oven - Boiler System -  CXGBD10.20

Product Features

  • 22 x 1/1 or 11 x 2/1 GN tray capacity gas boiler combi oven system
  • 68mm shelf distance
  • easyDial: all functions can be set on one operating level with digital display control panel
  • TriColour indicator ring - indicates the current operating status
  • Steam generated by high-performance boiler outside the cooking chamber
  • Natural Smart Climate (ACS+) cooking methods: Steam, Combi-steam, Convection:
  • Steam mode: (30-130C) with guaranteed steam saturation, Combi-steam mode: (30-250C) with automatic humidity adjustment, Convection mode: (30-250C) with optimised heat transfer
  • Function management:
  • Climate Management: Crisp&Tasty - 5 moisture-removal settings, BakePro - 5 levels of traditional baking, HumidityPro - 5 humidity settings, controllable fan - 5 speed settings
  • Quality Management: Airflow Management, BakePro, Multi-point core temperature probe
  • Production Management: 99 cooking profiles containing up to 9 steps, HACCP data storage, regenerating function, preheat and cool down function
  • Cleaning Management: ConvoClean: fully automated cleaning system including optional single-measure dispensing, integrated recoil hand shower
  • HygieniCare
  • USB port integrated in the control panel
  • LED lighting in oven cavity
  • Triple glass right-hinged appliance door
  • Door handle with safety latch and sure-shut function
  • Optional Extras:
  • Steam and vapour removal (build-in condensation hood), Ethernet / LAN interface, Sous-vide sensor or Core temperature sensor with external socket

Specifications

DIMENSIONS
Width 1120 mm
Depth 992 mm
Height 1058 mm
Weight 215kg

PACKED DIMENSIONS
Width 1345 mm
Depth 1140 mm
Height 1300 mm
Weight (including cleaning system) 253 kg

Safety clearances*
Rear 50 mm
Right 50 mm
Left (larger recommended for servicing) 50 mm
Top (for ventilation) 1000 mm *Heat sources must lie at a minimum distance of 500 mm from the
appliance.

LOADING CAPACITY
Max. number of food containers
Shelf distance 68mm
GN 1/1 (with standard rack) 22
GN 2/1 (with standard rack) 11
600 x 400 baking sheet (with appropriate rack) 16
Max. loading weight GN 1/1 / 600 x 400
Per combi steamer 100 kg
Per shelf 15 kg

ELECTRICAL SUPPLY
1N~ 230-240V 50/60Hz (1P+N+E)
Rated power consumption 0.6 kW
Rated current 2.7 A
Fuse 16 A
RCD (GFCI), frequency converter Type A
(singlephase) (recommended), type B/F (optional)
3 Pin plug (10 Amp) Cordset fitted

GAS SUPPLY
Gas Connection for natural or LPG R3/4
Installation conditions customer premise
Nominal gas consumption 122 MJ/hr
Convection power output 115 MJ/hr
Steam generator output 122 MJ/hr
Supply flow pressure
Natural Gas 1.13kPa – 3kPa
LPG 2.75kPa – 4kPa

Spec Sheet for CXGBD10.20
