Sustainable & Efficient
Designed for efficiency, this model features a variable-speed magnetic DC pump motor and environmentally friendly R290 natural refrigerant. Combined with high-grade foamed insulation and a standby function, it helps reduce both energy and water consumption.
Durable & Hygienic Construction
Built with food-grade stainless steel components (AISI 430) and a closed water circuit, the machine protects the ice-making process from contamination. The closed cell system ensures clean, consistently formed ice cubes.
Advanced Technology
Smart water flow technology adjusts pump speed throughout the ice-making cycle to improve performance and prevent chipped or cloudy cubes. A simple control panel allows easy adjustment of ice cube dimple size.
Smart & Long-Lasting Design
Automated cleaning and maintenance notifications help keep the machine running efficiently. Key components like the water tank and DC pump are easily removable for quick servicing.
Compact & Space-Saving
The compact FlexiCUBE design allows the unit to fit easily into tight kitchen or bar spaces without sacrificing ice production capacity.
Plug & Play Installation
An integrated drain pump allows flexible installation up to 10 metres from the drain and 1.5 metres in height, making setup quick and convenient.
SPECIFICATIONS:
- Exterior: Stainless Steel AISI 441, Galvanized Steel (Rear)
-
Ice Production Capacity (24 Hours):
- Approx. 53kg @ 10°C Air Temperature / 10°C Water Temperature
- Approx. 46kg @ 21°C Air Temperature / 15°C Water Temperature
- Approx. 37kg @ 32°C Air Temperature / 21°C Water Temperature
- Maximum Storage Capacity: Approx. 26kg (Bin Control Setting: Approx. 18kg)
- Width: 633mm
- Depth: 506mm
- Height: 930mm (840mm without legs)
- Net Weight: 49kg
- Packed Weight: 59kg
- Cooling: Air
- Power Supply: 1 Phase, 220–240V, 50Hz, 10A Plug
- Amperage: Running: 2.1A, Rated Motor: 2.1A, Starting: 11A
- Refrigerant Charge: R290 / 110g
-
Operating Conditions:
- Ambient Temperature: 1°C to 40°C
- Water Supply Temperature: 5°C to 35°C
- Water Supply Pressure: 0.07–0.8MPa (0.7–8bar)
- Voltage Range: Rated Voltage ±6%
- Electric Consumption: 305W
-
Water Consumption per 24 Hours:
- Approx. 0.22m³ @ 10°C Air Temperature / 10°C Water Temperature
- Approx. 0.14m³ @ 21°C Air Temperature / 15°C Water Temperature
- Approx. 0.11m³ @ 32°C Air Temperature / 21°C Water Temperature
- Electrical Circuit Breaker Protection: 5A
- Heat Rejection (AT 32°C, WT 21°C): 830W
- Accessories Included: Installation Kit, Legs, Scoop
- Package Dimensions: 735 × 570 × 1012mm
-
GEM Number: AIM0009
Warranty: 3 years Parts and Labour on the entire unit. 5 years (parts and labour) on evaporator. 5 years (parts only) compressor and air cooled condenser coil.
